InspirAIR� Side Classic Heat recovery ventilation unit

InspirAIR� Side Classic

Heat recovery ventilation unit

Heat recovery ventilation solution that matches the pace of occupant lifestyles.
InspirAIR� Side Classic InspirAIR� Side Classic
Download CAD Library file
InspirAIR� Side Classic
Heat recovery ventilation solution with filtered incoming air and indoor air renewal without heat loss.
InspirAIR� Side Classic

The + products

  • more purified air: up to 90% of bacteria, pollen and fine particles eliminated,
  • more design: pure and minimalist lines to blend in with the most demanding interiors,
  • more comfort: balances your indoor air while insulating from outdoor noise.
  • more control: alter the indoor quality at any time using the AldesConnect® app or let Walter® do it for you.

General and permanent ventilation of dwelling with heat recovery on exhaust air to pre-heat incoming air.

Incoming air is purified with custom filters to ensure clean air throughout the dwelling.

  • material:
    • PPE body and metal panels,
  • configuration:
    • left or right (2 versions),
  • airflow:
    • 150, 240, 370,
  • 100% bypass as standard,
  • Classic control keypad,
  • four modes:
    • holiday,
    • auto,
    • boost,
    • guest.
  • horizontal installation on ceiling or vertical on wall,
  • condensate outlet connected to PVC Ø 32 mm duct,
  • installation in heated space recommended.
References Available filters Insulation material Type of exchanger Type of motor
11023453 - InspirAIR® Side 150 Classic RH
  • pollen:
    • Coarse 65%,
  • particles:
    • ePM10 50%,
  • fine particles:
    • ePM1 0 85%,
    • ePM2.5 65%.
  • bacteria:
    • ePM2.5 95%,
    • ePM1 80%.
  • VOC:
    • ePM10 85%,
    • ePM2.5 65%.

Sensitive

EC

11023454 - InspirAIR® Side 150 Classic LH
  • pollen:
    • Coarse 65%,
  • particles:
    • ePM10 50%,
  • fine particles:
    • ePM1 0 85%,
    • ePM2.5 65%.
  • bacteria:
    • ePM2.5 95%,
    • ePM1 80%.
  • VOC:
    • ePM10 85%,
    • ePM2.5 65%.

Sensitive

EC

11023457 - InspirAIR® Side 150 Classic Modbus Right side
  • pollen: - Coarse 65 % > particles: - ePM10 50% > fine particles: - ePM1 0 85% - ePM2.5 65% > bacteria:- ePM2.5 95% - ePM1 80%> VOC: - ePM10 85% - ePM2.5 65%.

Sensitive

EC

11023458 - InspirAIR® Side 150 Classic Modbus Left side
  • pollen: - Coarse 65 % > particles: - ePM10 50% > fine particles: - ePM1 0 85% - ePM2.5 65% > bacteria:- ePM2.5 95% - ePM1 80%> VOC: - ePM10 85% - ePM2.5 65%.

Sensitive

EC

11023310 - InspirAIR® Side 240 Classic RH
  • pollen:
    • Coarse 65%,
  • particles:
    • ePM10 50%,
  • fine particles:
    • ePM1 0 85%,
    • ePM2.5 65%.
  • bacteria:
    • ePM2.5 95%,
    • ePM1 80%.
  • VOC:
    • ePM10 85%,
    • ePM2.5 65%.

Sensitive

EC

11023311 - InspirAIR® Side 240 Classic LH
  • pollen:
    • Coarse 65%,
  • particles:
    • ePM10 50%,
  • fine particles:
    • ePM1 0 85%,
    • ePM2.5 65%.
  • bacteria:
    • ePM2.5 95%,
    • ePM1 80%.
  • VOC:
    • ePM10 85%,
    • ePM2.5 65%.

Sensitive

EC

11023447 - InspirAIR® Side 240 Classic Modbus Left side
  • pollen: - Coarse 65 % > particles: - ePM10 50% > fine particles: - ePM1 0 85% - ePM2.5 65% > bacteria:- ePM2.5 95% - ePM1 80%> VOC: - ePM10 85% - ePM2.5 65%.

Sensitive

EC

11023446 - InspirAIR® Side 240 Classic Modbus Right side
  • pollen: - Coarse 65 % > particles: - ePM10 50% > fine particles: - ePM1 0 85% - ePM2.5 65% > bacteria:- ePM2.5 95% - ePM1 80%> VOC: - ePM10 85% - ePM2.5 65%.

Sensitive

EC

11023314 - InspirAIR® Side 370 Classic RH
  • pollen:
    • Coarse 65%,
  • particles:
    • ePM10 50%,
  • fine particles:
    • ePM1 0 85%,
    • ePM2.5 65%.
  • bacteria:
    • ePM2.5 95%,
    • ePM1 80%.
  • VOC:
    • ePM10 85%,
    • ePM2.5 65%.

Sensitive

EC

11023315 - InspirAIR® Side 370 Classic LH
  • pollen:
    • Coarse 65%,
  • particles:
    • ePM10 50%,
  • fine particles:
    • ePM1 0 85%,
    • ePM2.5 65%.
  • bacteria:
    • ePM2.5 95%,
    • ePM1 80%.
  • VOC:
    • ePM10 85%,
    • ePM2.5 65%.

Sensitive

EC

11023448 - InspirAIR® Side 370 Classic Modbus Right side
  • pollen: - Coarse 65 % > particles: - ePM10 50% > fine particles: - ePM1 0 85% - ePM2.5 65% > bacteria:- ePM2.5 95% - ePM1 80%> VOC: - ePM10 85% - ePM2.5 65%.

Sensitive

EC

11023449 - InspirAIR® Side 370 Classic Modbus Left side
  • pollen: - Coarse 65 % > particles: - ePM10 50% > fine particles: - ePM1 0 85% - ePM2.5 65% > bacteria:- ePM2.5 95% - ePM1 80%> VOC: - ePM10 85% - ePM2.5 65%.

Sensitive

EC

InspirAIR� Side Classic InspirAIR� Side Classic
References A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) Weight (kg)
11023453 - InspirAIR® Side 150 Classic RH

600

160

200

1070

215

420

27

11023454 - InspirAIR® Side 150 Classic LH

600

160

200

1070

215

420

27

11023457 - InspirAIR® Side 150 Classic Modbus Right side

600

160

200

1070

215

420

27

11023458 - InspirAIR® Side 150 Classic Modbus Left side

600

160

200

1070

215

420

27

11023310 - InspirAIR® Side 240 Classic RH

600

160

250

1150

215

365

30

11023311 - InspirAIR® Side 240 Classic LH

600

160

250

1150

215

365

30

11023447 - InspirAIR® Side 240 Classic Modbus Left side

600

160

250

1150

215

365

30

11023446 - InspirAIR® Side 240 Classic Modbus Right side

600

160

250

1150

215

365

30

11023314 - InspirAIR® Side 370 Classic RH

670

160

300

1150

215

420

34

11023315 - InspirAIR® Side 370 Classic LH

670

160

300

1150

215

420

34

11023448 - InspirAIR® Side 370 Classic Modbus Right side

670

160

300

1150

215

420

34

11023449 - InspirAIR® Side 370 Classic Modbus Left side

670

160

300

1150

215

420

34

References Airflow at max. speed (m³/h)
11023453 - InspirAIR® Side 150 Classic RH

150

11023454 - InspirAIR® Side 150 Classic LH

150

11023457 - InspirAIR® Side 150 Classic Modbus Right side

150

11023458 - InspirAIR® Side 150 Classic Modbus Left side

150

11023310 - InspirAIR® Side 240 Classic RH

240

11023311 - InspirAIR® Side 240 Classic LH

240

11023447 - InspirAIR® Side 240 Classic Modbus Left side

240

11023446 - InspirAIR® Side 240 Classic Modbus Right side

240

11023314 - InspirAIR® Side 370 Classic RH

370

11023315 - InspirAIR® Side 370 Classic LH

370

11023448 - InspirAIR® Side 370 Classic Modbus Right side

370

11023449 - InspirAIR® Side 370 Classic Modbus Left side

370

References Frequency (Hz) Protection rating Max. current (A) Voltage (V) Max. power
11023453 - InspirAIR® Side 150 Classic RH

50

1,2

230

135

11023454 - InspirAIR® Side 150 Classic LH

50

1,2

230

135

11023457 - InspirAIR® Side 150 Classic Modbus Right side

50

1,2

230

135

11023458 - InspirAIR® Side 150 Classic Modbus Left side

50

1,2

230

145

11023310 - InspirAIR® Side 240 Classic RH

50

1,75

230

183

11023311 - InspirAIR® Side 240 Classic LH

50

1,75

230

183

11023447 - InspirAIR® Side 240 Classic Modbus Left side

50

1,75

230

183

11023446 - InspirAIR® Side 240 Classic Modbus Right side

50

1,75

230

183

11023314 - InspirAIR® Side 370 Classic RH

50

2

230

234

11023315 - InspirAIR® Side 370 Classic LH

50

2

230

234

11023448 - InspirAIR® Side 370 Classic Modbus Right side

50

2

230

234

11023449 - InspirAIR® Side 370 Classic Modbus Left side

50

2

230

234

  • PV CE number  :  ,
  • Identification no. QB37  :  ,
  • CETIAT Inspection Report number  :  ,
  • PassivHaus Institute Certification no.  :  ,
  • Technical Opinion no.  :  ,
  • Test standard  :  ,
  • Energy class ErP- Ventilation  :  A
  • Text ErP - Ventilation  :  Complies with eco-design regulation 1253/2014 and energy labelling regulation 1254/2014 for ventilation.Energy classes: see ErP Regulations page.,Complies with eco-design regulation 1253/2014 and energy labelling regulation 1254/2014 for ventilation.Energy classes: see ErP Regulations page.
  • Text ErP - Domestic hot water  :  ,
  • Text ErP - Cooling  :  ,
  • Eligibility for EEC  :  Yes
References Energy class - Average climate Ventilation energy class - Average climate
11023453 - InspirAIR® Side 150 Classic RH

A

A

11023454 - InspirAIR® Side 150 Classic LH

A

11023457 - InspirAIR® Side 150 Classic Modbus Right side

A

11023458 - InspirAIR® Side 150 Classic Modbus Left side

A

11023310 - InspirAIR® Side 240 Classic RH

A

11023311 - InspirAIR® Side 240 Classic LH

A

11023447 - InspirAIR® Side 240 Classic Modbus Left side

A

11023446 - InspirAIR® Side 240 Classic Modbus Right side

A

11023314 - InspirAIR® Side 370 Classic RH

A

11023315 - InspirAIR® Side 370 Classic LH

A

11023448 - InspirAIR® Side 370 Classic Modbus Right side

A

11023449 - InspirAIR® Side 370 Classic Modbus Left side

A

Products and accessories references

  • InspirAIR® Side 150 Classic RH
    InspirAIR® Side 150 Classic RH
    11023453
    3587,85 (without VAT)
  • InspirAIR® Side 150 Classic LH
    InspirAIR® Side 150 Classic LH
    11023454
    3587,85 (without VAT)
  • InspirAIR® Side 150 Classic Modbus Right side
    InspirAIR® Side 150 Classic Modbus Right side
    11023457
    3796,80 (without VAT)
  • InspirAIR® Side 150 Classic Modbus Left side
    InspirAIR® Side 150 Classic Modbus Left side
    11023458
    3796,80 (without VAT)
  • InspirAIR® Side 240 Classic RH
    InspirAIR® Side 240 Classic RH
    11023310
    4034,10 (without VAT)
  • InspirAIR® Side 240 Classic LH
    InspirAIR® Side 240 Classic LH
    11023311
    4034,10 (without VAT)
  • InspirAIR® Side 240 Classic Modbus Left side
    InspirAIR® Side 240 Classic Modbus Left side
    11023447
    4432,05 (without VAT)
  • InspirAIR® Side 240 Classic Modbus Right side
    InspirAIR® Side 240 Classic Modbus Right side
    11023446
    4432,05 (without VAT)
  • InspirAIR® Side 370 Classic RH
    InspirAIR® Side 370 Classic RH
    11023314
    4681,95 (without VAT)
  • InspirAIR® Side 370 Classic LH
    InspirAIR® Side 370 Classic LH
    11023315
    4681,95 (without VAT)
  • Aldes
    InspirAIR® Side 370 Classic Modbus Right side
    11023448
    4801,65 (without VAT)
  • Aldes
    InspirAIR® Side 370 Classic Modbus Left side
    11023449
    4801,65 (without VAT)
